1. Innovative design and exquisite craftsmanship:
Our circular saw machines feature advanced innovative designs combined with exquisite craftsmanship to ensure durability and stability. The overall structure is sturdy and durable and can adapt to high-intensity industrial production environments.
2. Broad scope of application:
This equipment is specially designed for rods with diameters between 40-100mm and can flexibly handle materials of various diameters. Whether it is a small-diameter standard rod or a larger-diameter special material, it can be easily handled, providing users with a wide range of applicability.
3. Automatic turning and feeding function:
A notable feature is that the equipment is equipped with advanced automatic turning and feeding functions. This makes the entire cutting process more intelligent and efficient, greatly reducing the labor intensity of operators and improving production efficiency.
4. High-precision cutting:
The circular saw machine is equipped with a high-precision cutting system to ensure that each cut is completed at the precise position. This is particularly important for production tasks that require highly precise dimensions, ensuring the quality and consistency of the final product.
5. High-efficiency motor and variable speed control:
To ensure the efficient performance of the equipment, we use high-power motors and equip them with a flexible variable speed control system. This allows users to adjust for different materials and cutting requirements, providing greater flexibility and customizability.
6. Easy operation and user-friendly design:
The operation interface of the circular saw machine is designed to be simple and intuitive, making it easy to learn and operate. The humanized design takes into account the user's usage habits, thereby reducing training costs and improving operating efficiency.
7. Safety performance:
In the design, we paid special attention to safety performance. The equipment is equipped with multiple safety protection mechanisms to ensure that the risk of accidents is minimized during operation and the safety of operators is protected.
8. Energy saving and environmental protection:
We use advanced energy-saving technology to ensure that the equipment operates efficiently while minimizing energy consumption. This not only helps reduce production costs but also meets contemporary society's requirements for environmental protection and sustainable development.
9. Regular maintenance and after-sales service:
To ensure the long-term and stable operation of the equipment, we provide regular maintenance services and have a complete after-sales service system to provide customers with all-around support.
Our bar automatic turning and feeding sawing 40-100mm circular saw machine will become an indispensable tool in industrial production with its advanced technology, performance, and comprehensive functions, providing customers with efficient, accurate, and safe cutting solutions.
|
Model |
NCJ-100 |
|
|
Cutting Capacity |
||
|
Bar |
● |
40-100 mm |
|
Angle material |
■ |
40-85 mm |
|
Round tube |
○ |
40-100 mm |
|
Square tube |
□ |
40-85 mm |
|
Head Spindle |
||
|
Application of TCT tungsten carbide circular sawblade |
Φ360×2.6 mm |
|
|
Application of HSS high speed steel circular saw blade |
Φ360×2.6 mm |
|
|
Rotation number of cutter |
70~130rpm |
|
|
Spindle driving motor |
15HP ( 11KW ) |
|
|
Tool gap compensation device |
Magnetic powder brake |
|
|
Tool Shockproof parallel block |
Tungsten carbide |
|
|
Tool Chip cleaner |
Steel brush disc |
|
|
Cut-off feeding way |
Rocker type IAC servo |
|
|
Clamp method |
Hvdraulic/Horizontal and vertical |
|
|
Sizing feding(GFC)mechanism |
||
|
Sizing feeding driving way |
AC servo motor/Precision ball screw |
|
|
Feed clamp mode |
Horizontal hydraulic |
|
|
End cutting length |
8-99 mm |
|
|
Residual material length |
60 mm( Shortest) |
|
|
GFC feeding amount |
6-800mm(Single time) |
|
|
Automatic feeding device |
||
|
Material length |
2000-6000 mm |
|
|
Material placement area |
2000mm |
|
|
Feeding way |
Hydraulic lifting material |
|
|
Angle material slip device |
Optional accessories |
|
|
Hydraulic device |
||
|
Hydraulic driving motor |
3.75Kw (3Hp)/4p |
|
|
Hydraulic driving pressure |
70 kg/cm² (7 MPa) |
|
|
Oil capacity |
110 liters |
|
|
Air Pressure device |
||
|
Working air pressure |
5-7kg/cm² (55~85psi) |
|
|
Machine size & weight |
||
|
Size (Lx Wx H) |
6800×1600×1700mm |
|
|
Weight |
7800 Kgs |
|
|
Equipment & device |
||
|
Automatic lubrication system |
Timing forced oil |
|
|
Automatic distributor |
Pneumatic reciprocating |
|
|
Chip conveyor |
Chain plate |
|
|
Oil mist cooling device |
Oil mist lubrication sprayer |
|
|
Cutting fluid cooling device |
0.09Kw/2p/Cycle cooling |
|
|
Working lamp |
Quatrz lamp/Waterproof and dustproof |
|
